TRADITIONAL SHELTERS – POLYCARBONATE CLADDING
|
|
|
Recent addition to Traditional Cycle Shelters range. Not yet illustrated.
|
|
|
Traditional Design Shelters are now available with ultra modern Polycarbonate Panels and Roof giving high visibility combined with attractive appearance.
Same Modular Construction as other Traditional Design models, with similar frame and purlin specifications but with clear exterior grade polycarbonate cladding which is impact resistant, UV stable, Class 1 fire resistant and will not discolour.
OPTIONS: Rainwater guttering and down pipes
| Number of shelter bays |
1 |
2 |
3 |
4 |
| Overall Lengthmetres |
2 |
3 |
4 |
6 |
9 |
12 |
| No cycles stored (A) |
6 |
9 |
12 |
19 |
29 |
39 |
| No cycles stored (B) |
4 |
6 |
8 |
12 |
20 |
26 |
| Shelter Reference |
80102 |
80104 |
80106 |
80108 |
80110 |
80112 |
| Extra Powder Coat Ref |
80128 |
80130 |
80132 |
80134 |
80136 |
80138 |
| Side Panels Reference |
80114 per side |
| Rear Panels Reference |
80116 |
80118 |
80120 |
80122 |
80124 |
80126 |
| Gates-Mesh Ref |
80328 |
80330 |
80332 |
80334 |
80336 |
80338 |
| Gates-Polycarbonate Ref |
80340 |
80342 |
80344 |
80346 |
80348 |
80350 |
All heights x depths 2m x 2m. Shelter lengths are based on indicated no. of cycles stored in the table above (A) free standing racks and (B) tubular stands or tubular stand racks.
|
|
|
|
|
|
